Dancing Floor LED Display

Pixel Pitch: 3.91/4.81/6.25/8.9mm
Cabinet Size: 500 x500x98mm
IP rating: IP43
Brightness Intensity: 2000CD/m²
Ave.Power Consumption: 150/160/165 W/m²

GET A QUOTE
Parameters
Module Specifications
Part Number P3.91 P4.81 P6.25 P8.9
Pixel Pitch 3.91mm 4.81mm 6.25mm 8.9mm
Module size 250x250X20mm 250x250X20mm 250x250X20mm 250x250X20mm
LED Configuration 1R1G1B SMD 1R1G1B SMD 1R1G1B SMD 1R1G1B SMD
Cabinet Specifications
Module Resolution 24x24dot 16x16dot 12x12dot 12x12dot
Cabinet Size 500x500mm 500x500mm 500x500mm 500x500mm
Cabinet Resolution 48x48dot 32x32dot 24x24dot 24x24dot
Cabinet Weight 12.5kg 12.5kg 12.5kg 12.5kg
Main Parameter
Pixel Density 65410dot/m² 43222dot/m² 25600dot/m² 12624dot/m²
IP Rating (front/back) IP43 IP43 IP43 IP43
Brightness Intensity 2000CD/m² 2000CD/m² 2000CD/m² 2000CD/m²
Gray Scale 14bit 14bit 14bit 14bit
Max.Power Consumption 450 W/m² 480 W/m² 470 W/m² 470 W/m²
Ave.Power Consumption 150 W/m² 165 W/m² 160 W/m² 160 W/m²
Refresh Frequency ≥1920HZ ≥1920HZ ≥1920HZ ≥1920HZ
Environmental INDOOR INDOOR INDOOR INDOOR
Brightness Adjustment 0 – 100 levels adjustable
Control Mode Synchronous display with control PC by DVI
Support Input Composite,S-Vido,Component,VGA,DVI,HDMI,HD_SDI
Operation Power AC110 / AC220 50/60HZ
Operating Temperature – 20℃~+60℃
Operating Humidity 10~90% RH
Operating Life 100,000hours

Advantages:



1. The high strength wear-resistant antiskid material can be directly trampled, carry up to 500 kg weight per square meter.
2. Can realize seamless splicing, enclosure optional combination, make the image more exquisite and complete.
3. Can realize the virtual scenario screen interactive, experience the magic of interaction effect.
4. High contrast, high refresh rate design, making the screen when rendering design without any delay phenomenon of ghosting.
5. Deep gray processing, RGB color, and brightness of the synchronous adjustment, color is rich and exquisite, clear and natural.
6. Big Angle of view, more can meet the demand of the stage.
7. Professional cooling channel design, to ensure that the screen body heat export quickly and efficiently, make product performance is not affected by heat.
8. Remove the replacement 8, support separate enclosure, maintenance more convenient.
9. Connectors to choose professional aviation plugs, quality safety guarantee.



Applications:



Can be widely used in bar, club, theatre, theatre, multi-function hall, coffee shop, hotel, stage performances, music hall, commercial buildings, airports, shopping malls, and other places.
